Research and finalisation of technology and procedure for manufacturing sacrificial anode meeting international quality standard
Abstract
With a casting temperature of 450oC, using a medium frequency induction furnace, obtained zinc anodes have a high quality, homogeneous structure and stable manufacture procedure. The electrochemical capacity of anode is higher than 780 Ah/kg and the close potential is more negative than -1.0V vs. Ag/AgCl reference electrode. The electrochemical characteristics and alloy components satisfy the strictest requirements for zinc sacrificial anode. The Vietnam Petroleum Institute’s sacrificial anode product has been certified by the international accreditation organisation DNV-GL to conform with DNV-RP-B401 standard and its sacrificial anode manufacture procedure has been assessed by Quacert to meet the ISO 9001:2015 standard.
References
2. Bộ Khoa học và Công nghệ. Hệ thống quản lý chất lượng - Các yêu cầu. ISO 9001:2015.
3. Det Norske Veritas. Cathodic protection design. Recommended DNV-RP-B401. 2010.
4. International Organization for Standardization. Preparation of steel substrates before application of paints and related products - Visual assessment of surface cleanliness. ISO 8501.
5. International Organization for Standardization. Hot dip galvanized coatings on fabricated iron and steel articles - Specifications and test methods. ISO 1461:2009.
6. ASTM International. Standard test method for chemical analysis of zinc - 5% aluminum-mischmetal alloys by ICP Emission Spectrometry. ASTM E1277-96.
7. Military specification: Anodes, sacrificial zinc alloy. MIL-A-18001K. 1991.
8. Bộ Khoa học và Công nghệ. Anode hy sinh - Yêu cầu kỹ thuật. TCVN 10263:2014.
9. International Organization for Standardization. Petroleum, petrochemical and natural gas industries - Cathodic protection of pipeline transportation systems - Part 2: Offshore pipelines. ISO 15589-2:2012.
